SensorSwitch Wall Mount Motion Sensor Switch, Passive Infrared Wall Switch and Occupancy Sensor and Dusk-to-Dawn Photocell, WSX Series, Single Relay, Ivory

Bring smart, automatic lighting control to busy spaces with the WSX Series Wall Switch Occupancy Sensor. This indoor motion sensor uses PIR technology to monitor small movements up to 20 ft. and large movements beyond 36 ft., delivering confident, wall-to-wall coverage in private offices, private restrooms, closets, and copy rooms. As a practical motion detector switch, it supports LEDs, electronic and magnetic ballasts, CFLs, and incandescent lights, and its integrated photocell (disabled by default) can keep lights from turning on when daylight is present. Installation is straightforward thanks to a convertible neutral design that works with or without a neutral, plus interchangeable line and load wires that make it impossible to wire backwards. Time delay and operating modes are push-button adjustable; sensitivity is factory-tuned for reliable detection. Use it as a motion sensor for light, motion switch for lights, or motion light sensor to cut wasted energy while keeping rooms welcoming and hands-free.

• MOTION SENSOR LIGHT SWITCH: Sensor Switch WSX Series wall switch PIR motion sensor provides simple, cost-effective control for offices, restrooms, closets, copy rooms, and other small spaces; Compatible with LEDs, ballasts, CFLs, and incandescent lights
• PIR COVERAGE PATTERN: PIR sensor detects small motion (hand movements) at distances up to 20' and large motion (walking) beyond 36'; Wall-to-wall coverage supports reliable response; Adjustable time delay and operating modes are set via push-button
• ADDITIONAL FEATURES: Integrated dusk-to-dawn photocell (disabled by default) prevents light from turning on if sufficient daylight is present; Vandal resistant lens on the sensor ensures durability; Push-button programmable without removing cover plate
• SETUP DETAILS: Patent-pending wiring method enables the motion light sensor to function either with or without a neutral connection; Line and load wires are interchangeable to prevent wiring backwards; Programmable via Sensor Switch VLP app or push button
• SPECIFICATIONS: Indoor motion sensor is dual voltage (120-277V); UL certified and RoHS compliant; Measures 2.74" H x 1.68" W x 1.63" D; Motion detector switch mounting height 30–48"; 5-year limited warranty
